Auto Finger joint shaper line MXZ3515D

Machine Parameter:

Model

MXZ3515D-Ⅱ

MXZ3515TD-Ⅱ(with glue function)

Max process width

800mm

800mm

Max process thickness

150mm

150mm

Max Process length

1000mm

1000mm

Cutter speed

6000r/min

6000r/min

Crossed saw speed

5600r/min

5600r/min

cropping saw speed

5000r/min

5000r/min

Cutter diameter

160mm

160mm

Cutter spindle diameter

70mm

70mm

Cutter motor power

15kw

15kw

Saw motor power

7.5kw

7.5kw

Feeder motor power

0.375kw

0.375kw

Servo motor power

1.5kw

1.5kw

Working air press

0.5-0.8Mpa

0.5-0.8Mpa

Machine weight

2000kg

2200kg

Machine sizes

2620×2050×1400mm

3040×2050×1551mm

Machine Parameter:





MF758A

MF758B

MF758C

Working Table Length

1150mm

1150mm

1150mm

Working Table Width

800mm

800mm

800mm

Motor Power

0.37kw

0.37kw

0.37kw

Machine Sizes

1180x1770x920mm

1180x980x920mm

1180x980x920mm
