MJ3971BX650
|
MJ3971BX400 |
MJ3971BX300 | |
Max. Working size
| 650x300mm | 400x300mm | 300x300mm |
Distance from saw blade
| 3~200mm | 3~200mm | 3~200mm |
Width of conveyer belt
| 635mm | 385mm | 285mm |
Diameter of saw wheel
| 711mm | 711mm | 711mm |
Feed speed
| 0~18m/min | 0~18m/min | 0~18m/min |
Saw wheel motor
| 22kw | 18.5kw | 15kw |
Hydraulic pressure
| 55kg/cm2 | 55kg/cm2 | 55kg/cm2 |
Diameter of dust suction pipe | 102mm x2 | 102mm x2 | 102mmx2 |
Width of conveyor belt
| 5180x50x0.9mm | 4572x40x0.9mm | 4572x40x0.9mm |
Saw kerf
| 1.4-1.6mm | 1.4-1.6mm | 1.4~1.6mm |
Machine size(mm)
| 3000x2250x2000 | 3000x2250x2000 | 3000x2250x2000 |
Net weight
| 1800kg | 1650kg | 1650kg |
