Working width | 20-230mm |
Working thickness | 10-120mm |
Min. working length | 600mm |
Feeding speed | 10-35m/min |
Spindle speed | 7000r/min |
Cutter inner size | 40mm |
Flat cutter size | 100-125mm |
1st Bottom shaft motor | 5.5kw |
Right shaft motor | 4kw |
Left shaft motor: 4kw | 4kw |
1st Upper shaft motor | 7.5kw |
2nd Upper shaft motor | 5.5kw |
2nd Bottom shaft motor | 5.5kw |
Feeding motor power | 5.5kw |
Lifting motor power | 0.75kw |
Total motor power | 38.25kw |
Packing size | 4050*1600*1750mm |
Weight | 3900kgs |
