Model | MZB73216D | MZB73216C | MZB73216A | MZB73226B | MZB73226L |
Max working sizes | 2440mm | 2700mm | 2800mm | 2800mm | 2800mm |
Min working sizes | 130mm | 130mm | 130mm | 130mm | 130mm |
Max drilling depth | 60mm | 60mm | 60mm | 60mm | 60mm |
Max working thickness | 75mm | 75mm | 75mm | 75mm | 60mm |
Driller Quantity | 126pcs | 126pcs | 126pcs | 132pcs | 132pcs |
Total Motor power | 9kw | 9kw | 9kw | 12kw | 16.5kw |
Driller Speed(rpm) | 2840 | 2840 | 2840 | 2840 | 2840 |
Working table High | 920mm | 920mm | 920mm | 920mm | 920mm |
Working air pressure | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
Machine weight | 2800kgs | 2800kgs | 2800kgs | 3200kgs | 3500kgs |
Machine sizes (mm) | 4000x1300x1650 | 4000x1300x1650 | 4500x1300x1650 | 4500x1300x1650 | 4700x1400x1650 |
